ALLNET IP Kamera Bullet / Outdoor / 5MP / IR / Low-Light / Motorisiertes Vario-Objektiv / 93° / ALL-CAM2496v3-LEFN

https://www.allnetfrance.fr/web/image/product.template/70515/image_1920?unique=1fd7405
ALLNET IP Kamera Bullet / Outdoor / 5MP / IR / Low-Light / Motorisiertes Vario-Objektiv / 93° / ALL-CAM2496v3-LEFN

0,00 € 0.0 EUR 0,00 € Hors taxes

192,00 € Hors taxes

Connectez-vous pour voir les prix

  • Marque

Cette combinaison n'existe pas.

Contactez-nous
Marque: ALLNET

Conditions générales
Contactez-nous pour nous demander plus d'informations sur ce produit.

Partager

EAN: 4038816117830
Référence interne: ALL-CAM2496v3-LEFN

ALLNET IP Camera Bullet / Outdoor / 5MP / IR / Low-Light / Motorized varifocal lens / 93&deg / &quotALL-CAM2496v3-LEFN&quot

Highlights:

  • Optics
  • 1/2.7'', with light source
  • SmartIR, up to 50m (164 ft) IR distance
  • Up to 120 dB optical WDR (Wide Dynamic Range)
  • Compression
  • Ultra 265, H.265, H.264, MJPEG
  • &nbspTriple streams
  • &nbsp2592*1944@20fps in main stream
  • ROI (Region of Interest)
  • Network
  • ONVIF compliance
  • Setup
  • DC12V or PoE power supply
  • Wide voltage range of &plusmn25% in DC
  • Micro SD, up to 256 GB
  • Alarm 1 input and 1 output, audio 1 input and 1 output
  • IP67 ingress protection
  • IK10 vandal resistant

height=178

height=421

Technical Details:

&nbsp ALL-CAM2496v2-LEFN

Camera
Sensor 1/2.7&quot,5.0 megapixel, progressive scan, CMOS
Lens 2.7 ~ 13.5mm, AF automatic focusing and motorized zoom lens
DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m)
2.7 60.8 24.3 12.2 6.1
13.5 303.8 121.5 60.8 30.4
Angle of View (H) 106.25&deg~ 30.42&deg
Angle of View (V) 56.36&deg~ 17.22&deg
Angle of View (O) 110.34&deg~34.18&deg
Adjustment angle Pan: 0&deg ~ 360&deg Tilt: 0&deg ~ 90&deg Rotate: 0&deg ~ 360&deg
Shutter Auto/Manual, 1 ~ 1/100000s
Minimum Illumination Colour: 0.002Lux (F1.2, AGC ON)
0Lux with IR on
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N &gt56 dB
IR Range Up to 50m (164ft) IR range
Wavelength 850nm
IR On/Off Control Auto/Manual
Defog Digital Defog
WDR 120dB

Video
Video Compression Ultra 265, H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main profile, High profile
Frame Rate Main Stream:5MP (2880*1620), Max 30fps 4MP (2560*1440), Max 30fps 3MP (2304*1296), Max 30fps 1080P (1920*1080), Max 30fps
Sub Stream: 720P (1280*720), Max 30fps D1 (720*576), Max 30fps 640*360,Max 30fps 2CIF(704*288), Max 30fps CIF(352*288), Max 30fps
Third Stream: D1 (720*576), Max 30fps 640*360,Max 30fps 2CIF(704*288), Max 30fps CIF(352*288), Max 30fps
Video Bit Rate 128 Kbps~16 Mbps
OSD Up to 8 OSDs
Privacy Mask Up to 4 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas

White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital Noise Reduction 2D/3D DNR
Smart IR Supported
Flip Normal/Vertical/Horizontal/180&deg/90&degClockwise/90&degAnti-clockwise
Dewarping N/A
HLC Supported
BLC Supported

Audio
Audio Compression G.711
Two-way audio Supported
Suppression Supported
Sampling Rate 8KHZ

Storage
Edge Storage Micro SD, up to 256GB
Network Storage ANR

Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, SNMP
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API
Client EZStation
EZView
EZLive
Web Browser Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+

Interface
Audio I/O Input: impedance 35k&Omega amplitude 2V [p-p]
Output: impedance 600&Omega amplitude 2V [p-p]
Alarm I/O 1/1
Network 1 RJ45 10M/100M Base-TX Ethernet

Certifications
Certifications CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15

General
Power DC 12V&plusmn25%, PoE (IEEE 802.3af)
Power consumption: Max 8.0 W
Dimensions (L &times W &times H) 245 &times 86 &times 72mm (9.6&rdquo &times 3.4&rdquo &times 2.8&rdquo)
Net Weight 0.92kg (2.0lb)
Material Metal
Working Environment -30&degC ~ 60&degC (-22&degF ~ 140&degF), Humidity: &le95% RH (non-condensing)
Strorage Environment -30&degC ~ 60&degC (-22&degF ~ 140&degF), Humidity: &le95% RH (non-condensing)
Surge Protection 6KV
Ingress Protection IP67
Vandal Resistant IK10
Reset Button N/A
