Synergy 21 LED Dimmer Controller 2.4G wireless Dimming RF+Push *Milight/Miboxer*
| Marque: Miboxer |
EAN:
4038816248237
Référence interne:
PUSH1-3
PUSH1-3
2.4GHz Wireless Dimming (3-Zone)
AC100-240V powered
No wiring required, easy to implement PUSH switch to wirelessly control brightness and switch of lights.
Compatible with MiBoxer / Mi-Light 2.4G series lamps.
Using 2.4G RF wireless transmission technology, the control distance is 30 meters.
Supports 3 zones of independent control, unlimited number of lamps.
Supports 4096 levels of smooth dimming, the lowest brightness is 0.1%.
Dimming range: 0.1%-100%
Features
AC100-240V powered
No wiring required, easy to implement PUSH switch to wirelessly control brightness and switch of lights.
Compatible with MiBoxer / Mi-Light 2.4G series lamps.
Using 2.4G RF wireless transmission technology, the control distance is 30 meters.
Supports 3 zones of independent control, unlimited number of lamps.
Supports 4096 levels of smooth dimming, the lowest brightness is 0.1%.
Dimming range: 0.1%-100%
Parameters
| Product Name: | 2.4GHz Wireless Dimming (3-Zone) |
|---|---|
| Model No.: | PUSH1-3 |
| Input Voltage: | 100-240V~ 50/60Hz |
| Transmitting Power: | 6dBm |
| RF: | 2.4GHz |
| Control Distance: | 30m |
| IP Rating: | IP20 |
| Working Temperature: | -10~40°C |
| Standby Power Consumption: | 0.15W |
| Dimming Grayscale: | 4096 Levels |
| Dimming Range: | 0.1%-100% |
| EMC Standard (EMC): | ETSI EN 301 489-1 V2.2.3 ETSI EN 301 489-3 V2.1.1 |
| Safety Standard (LVD): | EN 61347-1:2015+A1: 2018 EN 61347-2-11: 2001+A1:2019 |
| Radio Equipment (RED): | ETSI EN 300 440 V2.2.1 |
| Certification: | CE, EMC, RED |
